BC-MS126 (YD126) Commercial Sliding Door System

group name: Aluminum Doors

Min Order: 30 set

brand name: BLOSSOM CHEER Door And Window Project Manufacturer

Nearest port for product export: Guangzhou, Shenzhen

Delivery clauses under the trade mode: FOB, CIF, EXW, Express Delivery

Acceptable payment methods: T/T, L/C, Credit Card, Cash

update time: Mon, 26 Oct 2026 10:05:38 GMT

contact supplier

Paramtents

Main Profile Wall Thickness 1.5mm
Frame Width 79mm two-track / 126mm three-track
Glazing Rebates 12mm single-glazing / 30mm double-glazing rebates
Screen Options Security mesh or high-transparency insect screen
Guide System Dedicated upper guide wheels
Bottom Rollers Heavy-duty quiet rollers
Track Rail 1.30mm stainless steel rail

Packging & Delivery

215cm x100cm x10cm
Min Order30 set

Briefing

BC-MS126 sliding doors use 1.5mm walls, 79mm/126mm frames, single and double glazing rebates and smooth top and bottom rollers.

Detailed

BC-MS126 (YD126) Commercial Sliding Door: Single/Double Glazing & Screen Integration

Featuring 1.5mm walls, 79mm/126mm frames, and 12mm/30mm glazing rebates, the BC-MS126 delivers cost-effective sliding with smooth top-guide and bottom rollers.

BC-MS126 cutaway showing 79mm and 126mm frames, 78mm by 33mm stiles, glazing rebates and stainless rails beside standard elevation drawings

Left: 45° cutaway highlighting 79mm/126mm frames, 78x33mm stiles, 12mm/30mm rebates, and stainless rails; Right: 1:1 elevation drawings.

3D Cutaway & Elevation

BC-MS126 sliding doors and screen integration in residential living rooms, kitchen partitions and bedroom balconies

Rendered into residential living rooms, kitchen partitions, and bedroom balconies, delivering breezy, bug-free living with ample daylighting.

Multi-Scenario Living

BC-MS126 frame screw joints, sash miter joints, perimeter brush seals, upper guide wheels and quiet bottom rollers

Captures 90° frame screws, 45° sash miter joints, multi-brush perimeter seals, upper guide wheels, and silent tandem rollers.

Jointing & Roller Assemblies

BC-MS126 (YD126) Core Physical & Structural Specification Matrix

Data sourced directly from factory specification sheets and extrusion drawings

Metric	Specification Value
Main Wall Thickness	1.5mm main profile walls (FRC1490 transmission rod wall thickness: 3.0mm)
Frame Width	79mm two-track frame; 126mm three-track frame
Jamb Size	126mm wide × 36mm high (standard three-track jamb)
Stile Size	78mm wide × 33mm high (structural load-bearing stile)
Glazing Rebate	12mm single-glazing rebate / 30mm insulated double-glazing rebate
Material Weight Data	9.2kg/m² (lightweight aluminum structure)
Screen Mesh	Optional security mesh or high-transparency insect screen sashes
Assembly Joint	90° screw-connected outer frame; 45° sash joints
Sealing Structure	Multiple gaskets and siliconized brush seals between frame and sash
Roller System	Dedicated upper guide wheels and heavy-duty quiet bottom rollers
Track Reinforcement	C125A16-X stainless steel rail (1.30mm wall thickness)
Max Sash Weight	Recommended glass door weight per sash: ≤120kg–150kg
Max Sash Size	Recommended sash width ≤1.2m; height ≤2.4m
Wind Resistance	Expected GB Class 5 (3.0kPa≤P3<3.5kPa)
Water Tightness	Exterior door configuration: expected GB Classes 2–3 (150Pa–250Pa)
Air Permeability	Expected GB Classes 4–5 (q1≤2.0m³/(m·h))
Sound Insulation	Double-glazed configuration: estimated weighted sound reduction Rw≈28dB–31dB

Hardware & Mechanics - Dual-Roller Kinetic Balancing, Stainless Rails & Multi-Seals

Optimized for high-frequency sliding, the BC-MS126 integrates top guide rollers, heavy silent bottom rollers, and stainless steel rails.

BC-MS126 dedicated nylon guide wheels inside the upper track

Micro-Structure Driven Scenario Configuration & Engineering Matrix

Providing modular configurations tailored to oceanfront villas, barrier-free corridors, and hurricane zones to streamline architectural specification.

Minimalist glazed doors connecting a hotel suite bathroom, open-plan kitchen and dining room, or flexible commercial office

Hotel Bathrooms, Kitchen-Dining Spaces & Office Partition Configurations

Coordinate swing, pivot and linked sliding doors with matching finishes, selected glazing and ceiling-recessed track arrangements.

Project & Technical References

Minimalist glazed and kinetic multi-slide door project and technical references

Minimalist Glazed & Kinetic Multi-Slide Door Project References

Explore References

Recommended Styles

Explore aluminum-wood door designs from our style library. Confirm the panel finish, frame configuration and dimensions for your project.

Flush Aluminum-Wood Door with HPL Finish — HBD007 HBD007

Concealed Aluminum-Wood Door with HPL Finish BC2340

Flush Aluminum-Wood Door with HPL Finish HBD004

Available Colors & Finishes

All wood grain finishes are bonded to the aluminum profile surface via vacuum heat transfer or PUR hot-melt lamination, ensuring zero batch-to-batch color deviation between metal frames and wooden door panels. For overseas projects, international RAL/NCS color cards are available for customized color matching.
