BC-S128 (PS128) Modular Lift-Slide Door System
- group name
- Aluminum Doors
- Min Order
- 30 set
- brand name
- BLOSSOM CHEER Door And Window Project Manufacturer
- Nearest port for product export
- Guangzhou, Shenzhen
- Delivery clauses under the trade mode
- FOB, CIF, EXW, Express Delivery
- Acceptable payment methods
- T/T, L/C, Credit Card, Cash
- update time
- Mon, 26 Oct 2026 11:28:22 GMT
Paramtents
Frame Depth 128mm
Aluminum Profile 2.2mm wall thickness, 6063-T5 alloy
Sash Width 72mm standard / 84mm reinforced
Slim Interlock 32mm with concealed thermal break strips
Maximum Sash Weight 600kg
Glass Thickness Up to 37mm
Operating Modes: Standard sliding or lift-slide
Production Time 15-25 Days
Packging & Delivery
- 215cm x100cm x10cm
-
Min Order30 set
Briefing
Slim aluminum glass doors with swing, pivot and linked sliding options, heavy-duty top tracks and clear, threshold-free access.
Detailed
BC-S128 (PS128) Modular Lift-Slide System: 600kg Load & 32mm Slim Interlock
Engineered on a modular platform, the BC-S128 combines 2.2mm walls, rigid-flexible seals, and 600kg sash loads to deliver expansive views via 32mm slim interlocks.
Visualizes installations in oceanfront penthouses and luxury resorts, accentuating unobstructed glass daylighting and panoramic horizons.
Architectural In-Situ Renderings
Captures 6063-T5 alloy sections, nylon-silicone composite seals, heavy-duty lift-slide bogies, and flush embedded barrier-free sill details.
Macro Mechanical Details
Unique Engineering Highlights
Shared Interior/Exterior Profiles
Platform Material Efficiency
Frame, top track, and bottom sill share identical profile sections, reducing standard inventory parts by 50% to optimize warehouse storage.
32mm Seamless Interlock Aesthetics
Concealed Thermal Barrier
Integrates central thermal-break profiles flush within 32mm interlocks without exposed strips, eliminating thermal bridge risks.
Fully Concealed Grooves & Bolts
Full-Cover Flush Aesthetics
Covered accessory grooves conceal technical mechanisms even when sashes are open, hiding perimeter frame bolts entirely.
BC-S128 (PS128) Core Physical & Structural Specification Matrix
| Core Physical Specifications & Cross-Sectional Dimensions | Officially Measured Engineering Parameters |
|---|---|
| Frame Depth | 128mm modular, versatile frame system depth |
| Wall Thickness | 2.2mm throughout; 6063-T5 ultra-high-precision aluminum alloy |
| Sash Visible Width | 72mm (standard version) / 84mm (reinforced version for oversized sashes) |
| Interlock Width | 32mm ultra-narrow interlock (thermal break strips recessed and concealed) |
| Frame Visible Width | 40mm ultra-narrow outer frame sightline |
| Max Sash Weight | 600kg (maximum load capacity per sash) |
| Glass Pocket Depth | ≤37mm (accommodates extra-thick triple glazing or laminated insulated glass) |
| Thermal Insulation | K≤2.0 W/(m²⋅K) |
| Solar Heat Gain | 0.2<SHGC≤0.3 (blocks summer solar heat radiation) |
| Sound Insulation | Rw≥36dB (when paired with argon-filled laminated insulated glass) |
| Air Permeability | q1=0.75m³/(m⋅h) (Chinese National Standard Class 8) |
| Water Tightness | ΔP≥350Pa−500Pa+ (embedded high-watertightness track) |
| Wind Load Resistance | ≤5.0kPa (Chinese National Standard Class 9 / withstands Force 14 typhoons) |
| Material Efficiency | Identical profile sections for the top and bottom tracks and the inner and outer sides of the frame, reducing basic material types by approximately 50% |
| Track Expansion | Standard track X+1; expanded tracks X+N+2N+3N… |
| Corner Sealing | Rigid-flexible coupled seals (high-strength nylon support + elastic silicone deformation) |
Lift-Slide Dual Kinematics, Fully Concealed Hardware & 600kg Drive
Featuring standardized slots, the BC-S128 switches between sliding and lift-slide modes while fully concealing all accessory grooves and bolts.
Sliding & Lift-Slide Dual-Mode Conversion
Standardized hardware slots allow conversion between standard sliding and lift-slide kinematics via minimal modular parts.
Concealed Hardware Design
Outfits fully covered accessory grooves to hide mechanical components during sash operation, concealing perimeter frame bolts entirely.
600kg Heavy-Duty Lift Bogie Assemblies
Integrates certified heavy-duty bogie systems rated for 600kg loads, verified via 100,000 operational cycles for effortless glide.
Rigid-Flexible Coupling Corner Seals
Combines high-strength nylon rigid supports with flexible silicone gaskets for controlled deformation, sealing corner air-leakage paths.
Micro-Structure Driven Scenario Configuration & Engineering Matrix
Providing modular configurations tailored to oceanfront villas, barrier-free corridors, and hurricane zones to streamline architectural specification.
Hotel Bathrooms, Kitchen-Dining Spaces & Office Partition Configurations
Coordinate swing, pivot and linked sliding doors with matching finishes, selected glazing and ceiling-recessed track arrangements.
Submit project drawings to coordinate swing or pivot opening, double or triple top tracks, linked panel layouts, glazing, ceiling fixing and matching door finishes.
Project & Technical References
Recommended Styles
Explore aluminum-wood door designs from our style library. Confirm the panel finish, frame configuration and dimensions for your project.
Flush Aluminum-Wood Door with HPL Finish — HBD007
HBD007
Concealed Aluminum-Wood Door with HPL Finish
BC2340
Flush Aluminum-Wood Door with HPL Finish
HBD004
Available Colors & Finishes
All wood grain finishes are bonded to the aluminum profile surface via vacuum heat transfer or PUR hot-melt lamination, ensuring zero batch-to-batch color deviation between metal frames and wooden door panels. For overseas projects, international RAL/NCS color cards are available for customized color matching.
Premium No. 14
BCAW20
Premium No. 15
BCAW19
Premium No. 16
BCAW18
Premium No. 11
BCAW17
Premium No. 12
BCAW16
Premium No. 13
BCAW15
Premium No. 18
BCAW14
Premium No. 10
BCAW13
Premium No. 17
BCAW12
Premium No. 2
BCAW11
Premium No. 3
BCAW10
Premium No. 9
BCAW09
Modular Lift-Slide System Technical Specification Download Hub
Providing engineering submittals, AutoCAD node details, and certified lab test reports tailored to global developers, EPC contractors, and lead architects.
