Synchronous Texture Aluminum Frame Wood Door

group name: Alu-Wood Doors

Min Order: 30 set

brand name: BLOSSOM CHEER Door And Window Project Manufacturer

Nearest port for product export: Guangzhou, Shenzhen

Delivery clauses under the trade mode: FOB, CIF, EXW, Express Delivery

Acceptable payment methods: T/T, L/C, Credit Card, Cash

update time: Mon, 26 Oct 2026 18:56:37 GMT

contact supplier

Paramtents

Product Type Paint-Free Aluminum Frame Wood Door
Opening Method Swing
Door Leaf Thickness 45 mm
Panel Thickness Options 5 mm or 9 mm per Side
Aluminum Alloy 6063-T5 Primary Aluminum
Aluminum Skeleton Wall Thickness 2.0 mm
Aluminum Edge Banding Thickness 2.0 mm
Core Material Aluminum Honeycomb / Graphite Sound-Insulation Board
Surface Finish Synchronous Embossed Woodgrain
Production Time 15-25 Days

Packging & Delivery

215cm x100cm x10cm
Min Order30 set

Briefing

Wood-grain door with a 2.0mm aluminum skeleton, honeycomb core and paint-free panels for scratch, moisture and warp resistance.

Detailed

Synchronous Texture Aluminum Frame Wood Door

Synchronized woodgrain panels, a 2.0mm aluminum skeleton and an aluminum honeycomb core create a natural wood feel with scratch, moisture and warp resistance.

Synchronous Texture Door Engineering Specifications

Construction, material, finish and sizing specifications for the Synchronous Texture Aluminum Frame Wood Door, supporting project selection and fabrication planning.

Engineering Metric	Specification Value
Standard Door Leaf Thickness	45mm structural door leaf; two 5mm panels or two 9mm panels available
Main Load-Bearing Aluminum Skeleton	2.0mm wall thickness throughout the primary 6063-T5 aluminum alloy skeleton
Door Leaf Perimeter Edge Banding	One-piece aluminum edge banding with a 2.0mm wall thickness
Aluminum Casing Profile & Wall Thickness	30mm ultra-narrow casing with a 1.6mm main profile; or 45mm casing with a 1.8–2.0mm main profile
Acoustic Damping Core	High-density aviation-grade aluminum honeycomb core / homogeneous graphite sound-insulation board filling
Surface Pressing & Finish Options	Synchronous pressing: double-synchronous, super skin-feel, new rain-grain and micro-synchronous surfaces
Base Material Weathering Performance	6–11% moisture content; resistance to a 100°C temperature differential without cracking
Standard & Maximum Fabrication Size	Standard: 2250 × 920mm Maximum: 3000 × 1220mm for floor-to-ceiling doors
Clear Opening & Frame Sizing Formulas	Clear opening width + 50 = frame height Door leaf width + 34 = frame width Door leaf height + 26 = frame height, including 10mm bottom clearance All formula dimensions are in millimeters.
Whole-Door Sound Insulation	Estimated weighted sound reduction index: R_w ≈ 30–33 dB with graphite sound-insulation board

Magnetic Locks, Concealed Hinges & Hardware Compatibility

Configure magnetic locks, concealed hinges and compatible branded hardware for quiet closing, precise alignment and reliable operation of the Synchronous Texture Aluminum Frame Wood Door.

Synchronous texture aluminum frame wood door with magnetic locking, concealed hinges and compatible hardware interfaces

Synchronous texture door standard magnetic lock, inline silent magnetic lock and optional 7240 minimalist magnetic lock body

Project Applications & Door Configuration Options

Configure panel finishes, aluminum casings, core materials and hardware to suit your interior door requirements.

Synchronous Texture Aluminum Frame Wood Door Configurations

BC-S130 modular heavy-duty sliding window configurations for hurricane penthouses and expansive balconies

Coastal Penthouses, Large-Span Balconies & High-Rise Utility Configurations

Configure opening layout, laminated or insulated glazing, track and roller capacity, drainage, sealing, safety screening, and finishes around span, exposure, and daily-use requirements.

Verified Project & Laboratory Evidence

BC-S130 heavy-duty panoramic sliding window engineering application reference

BC-S130 Engineering Evidence Library

View Evidence Center

Recommended Styles

Explore aluminum-wood door designs from our style library. Confirm the panel finish, frame configuration and dimensions for your project.

Flush Aluminum-Wood Door with HPL Finish — HBD007 HBD007

Concealed Aluminum-Wood Door with HPL Finish BC2340

Flush Aluminum-Wood Door with HPL Finish HBD004

Available Colors & Finishes

All wood grain finishes are bonded to the aluminum profile surface via vacuum heat transfer or PUR hot-melt lamination, ensuring zero batch-to-batch color deviation between metal frames and wooden door panels. For overseas projects, international RAL/NCS color cards are available for customized color matching.
